Fuel Element with Bail Handle - PF986
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
The Baldwin PF986 Fuel Filter Element is a cartridge-style diesel fuel filter designed for compatible marine, industrial, and equipment fuel filter housings. It helps protect fuel injection components by filtering dirt, rust, fine debris, and fuel-borne contamination before fuel reaches critical downstream components.
This element features a built-in metal bail handle across the top cap, making removal easier from deep or tight canister-style fuel filter housings during routine service.
Key Features
- Baldwin cartridge-style diesel fuel filter element.
- Part number: PF986.
- Built-in metal bail handle for easier extraction.
- Designed for compatible canister-style fuel filter housings.
- Pleated cellulose filter media.
- Filtration reference: 9.8 micron nominal / 27 micron absolute.
- Helps protect fuel injection pumps, injectors, and fuel delivery components from abrasive contamination.
- Compact element design for tight fuel filter housings.
- Supplied with rubber sealing grommets where packaged.
- Commonly used in marine diesel, industrial, and equipment applications where specified.
Technical Specifications
- Filter type: cartridge diesel fuel filter element
- Part number: PF986
- Media type: pleated cellulose
- Nominal filtration rating: 9.8 micron reference
- Absolute filtration rating: 27 micron reference
- Overall height / length: 2-5/8 in. / 66.7 mm
- Outer diameter: 2-9/16 in. / 65.1 mm
- Inner diameter reference: 7/16 in. / 11.1 mm on one side
- Inner diameter reference: 1/2 in. / 12.7 mm on opposite side
- Service feature: metal bail handle
- Included seals: typically supplied with 2 rubber sealing grommets
Application Compatibility
Common application context includes fuel systems and equipment where Baldwin PF986 or a verified equivalent is specified, including:
- Select Yanmar diesel engine applications.
- Select Volvo Penta marine diesel applications.
- Select Komatsu industrial and earthmoving equipment applications.
- Compatible canister-style diesel fuel filter housings using this element size and seal layout.
Use this element only where the engine model, machine model, serial number, fuel filter housing, and parts manual confirm PF986 or an approved cross-reference.
Fitment Notice
Confirm fitment by engine or machine model, serial number, existing filter number, filter housing style, element height, outer diameter, inner diameter, and sealing grommet layout before ordering. Cartridge-style fuel filters can look similar but differ in sealing position, internal bypass path, overall height, and housing fit.
For marine diesel applications, verify both the engine manufacturer reference and the filter housing before installation.
When This Part Needs Replacement
Replace the fuel filter element at the manufacturer’s recommended service interval, during seasonal diesel service, after contaminated fuel exposure, or when the engine shows symptoms of restricted fuel flow such as hard starting, rough running, hesitation, smoke, loss of power, or stalling under load.
Replacement is also recommended if the filter element is dirty, damaged, fuel-soaked beyond normal service condition, swollen, collapsed, or if the sealing grommets are hardened, cracked, flattened, or missing.
Installation Notes
Shut the engine or equipment down safely and close the fuel supply if equipped. Clean the filter housing before opening it to prevent dirt from entering the fuel system. Use the metal bail handle to remove the old element carefully, then remove and discard the old sealing grommets.
Install the new element with the correct grommets in place and confirm it seats properly in the housing. Reassemble the filter bowl or cover according to the service procedure, prime and bleed the fuel system as required, then check carefully for leaks before returning the engine to service.
Alternate / Cross-Reference Part Numbers
- Baldwin PF986 — primary part number
- Volvo 6604946 — cross-reference reference; verify by application
- Volvo 6643218 — cross-reference reference; verify by application
- Donaldson P551175 — cross-reference reference; verify by application
- Fram C1191A — cross-reference reference; verify by application
- Bosch 1457431085 — cross-reference reference; verify by application
Parts Desk Insight
The bail handle is useful on this filter because many cartridge fuel elements sit deep inside canister housings. The most important fitment checks are the element height, outer diameter, inner sealing diameters, and grommet placement. If the element does not seat correctly, fuel can bypass the media and send contamination downstream.
