PSS Shaft Seal – 1" Shaft x 1-1/2" Stern Tube | 02-100-112
The PSS 02-100-112 is a Type A mechanical face shaft seal designed to replace a conventional stuffing box on inboard boats with a 1" propeller shaft and a 1-1/2" to 1-5/8" stern tube. Instead of packing that requires periodic adjustment and intentional dripping, the PSS uses a carbon-graphite stationary sealing face and a stainless-steel rotor to create a dripless seal that requires minimal routine maintenance.
The result is a dry bilge, no shaft wear from packing friction, and no need to haul the boat just to re-pack the gland. PSS seals are installed as standard equipment by builders and are accepted by the USCG.
Specifications
- Part Number: 02-100-112 (also 02100112)
- Shaft Diameter: 1"
- Stern Tube Diameter: 1-1/2" to 1-5/8"
- Type: Type A mechanical face seal
- Compressed Installation Length: approx. 6-1/4"
- Overall Length: approx. 6.875"
- Rotor Diameter: approx. 2.375"
- Required Bellows Compression: approx. 3/4"
- Weight: 1,361 g (3 lbs)
- UPC: 839662006972
Features
- Dripless mechanical face seal — eliminates the need for packing adjustment and intentional dripping
- Carbon-graphite stationary sealing face paired with a stainless-steel rotor
- Eliminates shaft wear caused by packing friction
- Hose-barb fitting for venting or cooling-water feed depending on vessel speed and installation
- Accepted by the USCG; installed as standard equipment by many builders
- Reduces bilge water accumulation and associated corrosion
Compatible Applications
- Inboard marine propulsion systems with a 1" propeller shaft
- Stern tubes measuring 1-1/2" to 1-5/8" outside diameter at the bellows attachment point
- Replacement for conventional stuffing boxes on sailboats and powerboats
- New builds and refit installations requiring a dripless shaft seal
Fitment Note
Both measurements are required to order correctly. Do not select this seal by shaft diameter alone. Confirm both the 1" shaft diameter and the 1-1/2" to 1-5/8" stern-tube diameter, along with available installation length around the shaft. PSS specifically advises confirming the stern-tube diameter before ordering — this is the most common sizing error.
Cross-Reference / Alternate Part Numbers
- 02-100-112
- 02100112
- 730-02100112 (distributor reference)
- 1918614 (retail reference)
Related Products
- PSS Shaft Seal – 7/8" Shaft
- PSS Shaft Seal – 1-1/4" Shaft
- PSS Shaft Seal – 1-3/8" Shaft
- PSS Shaft Seal – 2-1/2" Shaft x 3-1/2" Stern Tube
Parts Desk Insights
Best use case: The PSS seal is the right upgrade for any inboard boat owner who is tired of adjusting packing, dealing with bilge water from the stuffing box, or hauling the boat to re-pack the gland. It’s particularly well suited to boats that spend extended time in the water, where a conventional stuffing box requires more frequent attention.
The most common ordering mistake is measuring only the shaft. For this seal (02-100-112), the critical second number is the stern tube: 1-1/2" to 1-5/8". Measure the outside diameter of the stern tube where the bellows will attach — not the shaft log bore — before ordering. If your stern tube falls outside this range, a different PSS model is required. Also confirm you have at least 6-1/4" of clear installation length around the shaft before the coupling or cutlass bearing.
