Seachoice 50-22307 Fuel/Water Separating Filter Bracket – Powder-Coated Aluminum
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Seachoice 50-22307 – Fuel/Water Separating Filter Bracket
Part Number: 50-22307 (also referenced as 22307)
Brand: Seachoice
Type: Fuel/water separator mounting bracket
Material: Powder-coated aluminum
Port Size: 3/8"
UPC: 719249223070
Overview
The Seachoice 50-22307 is a powder-coated aluminum mounting bracket for marine fuel/water separating filter assemblies. The powder-coat finish provides corrosion resistance in the marine environment, while the 3/8-inch ports support good fuel flow for compatible spin-on filter systems. The kit includes two aluminum fittings and two plugs with pre-applied thread sealant, so the bracket is ready to connect to your fuel lines right out of the box.
For a stainless-steel version of this bracket, see the Seachoice 22308 Stainless-Steel Fuel/Water Separating Filter Bracket.
Key Features
- Powder-coated aluminum construction for corrosion resistance
- 3/8" ports for compatible fuel flow with standard marine fuel/water separators
- Includes two aluminum fittings and two plugs — hardware is aluminum to minimize galvanic corrosion
- Pre-applied thread sealant on the 3/8" NPT threaded plugs — ready to install
- Universal bracket design for use with multiple compatible filter assemblies
Compatible Applications
- Seachoice 22303 Water Separating Fuel Filter with Clear Bowl
- Seachoice 22401 Clearchoice™ See-Through Water Separating Fuel Filter
- Seachoice 20934 fuel/water separator (confirm availability)
- Racor B32013 compatible assembly
- Sierra 18-79281 and Sierra 18-7929 compatible references
- Verify that your filter or separator assembly uses a compatible mounting pattern and 3/8-inch fuel ports before ordering
Kit Contents
- 1x powder-coated aluminum mounting bracket
- 2x aluminum fittings
- 2x 3/8" NPT threaded plugs with pre-applied sealant
Dimensions & Weight
- Weight: 381 g (approx. 0.84 lb)
- Port size: 3/8"
- Refer to Seachoice product documentation for mounting hole pattern and bracket dimensions
When to Replace
Replace the bracket if the casting or threads are cracked, stripped, heavily corroded, distorted, or unable to maintain a secure and leak-free connection with the fuel fittings or filter assembly.
Installation Notes
- Shut off the fuel supply before beginning installation
- Mount the bracket securely in an accessible engine-compartment location, oriented to match your boat's fuel-line routing
- The included plugs have pre-applied thread sealant — inspect before use and reapply marine-grade thread sealant if needed
- Use marine-rated fuel hose and fittings, and follow the flow-direction markings on the connected filter assembly
- Pressure-check all connections for leaks before starting the engine
Cross-Reference / Alternate Part Numbers
- Seachoice: 50-22307 / 22307
- UPC: 719249223070
- Stainless-steel version: Seachoice 22308
Parts Desk Insights
Best Use Case: The 50-22307 is the right choice for freshwater boat installations or enclosed engine compartments where a standard powder-coated aluminum bracket will hold up well. It pairs directly with the Seachoice 22303 and 22401 filter assemblies and is a cost-effective option when stainless-steel construction is not required.
Common Issues: The most common question is aluminum versus stainless. If the engine bay sees frequent water exposure, spray, or salt air, consider the Seachoice 22308 stainless-steel bracket instead. Also confirm port size (3/8") and mounting footprint compatibility with your specific filter assembly before ordering — not all marine fuel/water separators use the same bracket pattern.
Related Products
- Seachoice 22308 Stainless-Steel Fuel/Water Separating Filter Bracket — stainless-steel upgrade version
- Seachoice 22303 Water Separating Fuel Filter with Clear Bowl — compatible filter for this bracket
- Seachoice 22401 Clearchoice™ See-Through Water Separating Fuel Filter — compatible Clearchoice filter
- Seachoice 22306 Replacement Clear Bowl Kit for Fuel/Water Separators — replacement bowl for compatible filter assemblies
- Seachoice 50-20937 Fuel/Water Separating Filter – 10 Micron — 10-micron spin-on filter for Volvo Penta / OMC systems
- Seachoice 50-20938 Fuel/Water Separating Filter – Volvo/OMC – 10 Micron — companion spin-on filter
