Ideal Tridon — Stainless Worm Gear Hose Clamp SAE 72 3"-5" — IDE-HAS72
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
The Ideal Tridon HAS72, also referenced as IDE-HAS72, is a heavy-duty stainless steel worm gear hose clamp for larger hose and pipe connections requiring a 3" to 5" clamping range. This SAE Size 72 clamp uses a 1/2" wide Hy-Gear style band with stainless steel band, housing, and screw construction, making it well suited for above-water marine service, automotive systems, industrial hose connections, and other high-vibration clamping applications where corrosion resistance and secure tightening are important.
Key Features
- Product code: HAS72 / IDE-HAS72
- Clamp size: SAE Size 72
- Manufacturer series reference: Ideal Tridon 67-4 Series / AA52506-F Type F
- Manufacturer item reference: 67004-0072
- Diameter range: 3" to 5" / 76 mm to 127 mm
- Band width: 1/2" wide band
- Band material: 301 stainless steel
- Housing material: 301 stainless steel
- Screw material: 305 stainless steel
- Screw style: 5/16" hex-head slotted worm gear screw
- Standard compliance: J1508 AA52506 Type F
Application Compatibility
This clamp is intended for large-diameter hose connections in automotive, industrial, MRO, equipment, and above-water marine applications. It is commonly used where a stainless worm gear clamp is required around a hose, duct, tube, pipe sleeve, or similar round connection within the 3" to 5" outside diameter range.
For marine use, this clamp is best suited for above-water or protected applications where stainless steel corrosion resistance is required. For below-waterline, fuel, exhaust, steering, or critical fluid systems, always confirm the clamp style, material grade, and installation requirements against the vessel manufacturer’s service guidelines or applicable marine standards.
Fitment Notice
Confirm the actual outside diameter of the hose after it is installed over the barb, fitting, pipe, or tube. The clamp must tighten within its working range of 3" minimum to 5" maximum. Do not size the clamp from hose nominal ID alone, since hose wall thickness and fitting diameter can change the required clamp size.
When This Part Needs Replacement
Replace the clamp if the band is distorted, cracked, stretched, pitted, heavily corroded, or no longer tightens smoothly. The clamp should also be replaced if the worm screw slips, strips, seizes, or shows rust lock that prevents proper tightening. On marine and high-vibration installations, inspect clamps during seasonal service and replace any clamp that shows loss of tension, corrosion at the housing, or visible wear at the band perforations.
Installation Notes
Install the clamp squarely over the hose and position it behind the fitting bead or barb where applicable. Tighten evenly using the 5/16" hex-head or slotted screw without over-tightening, which can cut into the hose or deform the fitting. For large hose connections, inspect the hose end, fitting surface, and any adjacent clamps at the same time. Replace hardened, cracked, swollen, or oil-soaked hose rather than relying on extra clamp tension to stop a leak.
Alternate/Superseded Part Numbers
- Marisol / product code: IDE-HAS72
- Common product code: HAS72
- Ideal Tridon manufacturer reference: 67004-0072
- Series reference: 67-4 Series / AA52506-F Type F
- Clamp size reference: SAE Size 72
Parts Desk Insight
For hose clamps, the size number is only part of the match. The important check is the installed hose outside diameter. HAS72 is the correct range when the clamping point measures between 3" and 5", making it useful for larger hose connections where a standard smaller clamp will not provide enough diameter adjustment or band engagement.
