Johnson Pump F2P10-19 Deck Wash & Multipurpose Flexible Impeller Pump 10-24180-1 – 12V
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Johnson Pump F2P10-19 Deck Wash & Multipurpose Flexible Impeller Pump – 12V
Part Number: 10-24180-1 (also referenced as 10-24180-01)
Brand: Johnson Pump Marine
Model: F2P10-19
Current Replacement: 10-24886-01
Product Overview
The Johnson Pump F2P10-19 is a 12V self-priming flexible-impeller pump designed for a wide range of marine fluid-transfer applications. It features an ignition-protected DC motor with built-in thermal overload protection, making it safe for use in marine environments.
- Voltage: 12V DC
- Pump type: Flexible impeller, self-priming
- Flow rate: Approx. 15 L/min (4 GPM)
- Hose connection: 1/2 inch
- Impeller: 09-1077B-9 nitrile
- Seal: Lip seal
- Dimensions: Approx. 172 × 117 × 78 mm
- Weight: Approx. 1.6 kg (3.5 lb)
- Ignition-protected motor with thermal overload protection
Compatible Applications
- Deck wash and general boat wash-down
- Bilge pumping
- Fresh-water pumping and transfer
- Water circulation
- Oil transfer
- Diesel fuel transfer
- Other compatible marine fluid-transfer applications
Not suitable for: Paraffin or other thin petroleum products.
Fitment Note: This is the 12V version with 1/2-inch hose connections. The 24V version is a separate part number. Confirm vessel voltage and hose size before ordering. The current production replacement for this pump is 10-24886-01.
When to Replace or Service
- Pump no longer self-primes reliably
- Significant reduction in flow rate
- Leakage at the shaft or housing
- Motor becomes intermittent or unreliable
- Inspection reveals significant impeller wear
Installation Notes
- Mount securely using compatible 1/2-inch ID hose
- Check hose routing for kinks or restrictions
- Wire to an appropriately fused 12V DC circuit
- Do not run dry — flexible impellers can be damaged quickly without fluid
Part Number Cross-Reference
- Original: 10-24180-1
- Also listed as: 10-24180-01
- Current replacement: 10-24886-01
- Replacement impeller: 09-1077B-9
Related Products
- Johnson Pump 09-801B Impeller
- Johnson Pump 09-808B-1 Impeller Kit
- Johnson Pump 09-45587 Service Kit
- SHURflo ProBlaster II Washdown Pump Kit – 12V
- Johnson Pump Flush-Mount Deck Wash Fitting – 316 Stainless (JP61121)
Parts Desk Insights
The most common point of confusion with this pump is the part number format: 10-24180-1 and 10-24180-01 refer to the same unit. If a customer needs a direct replacement, the current production part is 10-24886-01. For service rather than full replacement, the nitrile impeller (09-1077B-9) handles the majority of performance issues. Always confirm 12V voltage and 1/2-inch hose size before ordering — these are the two most common ordering errors on flexible impeller pumps.
