Uflex UP20FM Front Mount Hydraulic Steering Helm – SeaStar Compatible, 3/4" Aluminum Shaft
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Uflex UP20FM Front Mount Hydraulic Steering Helm – SeaStar Compatible, 3/4" Aluminum Shaft
The Uflex UP20FM is the entry-level front-mount hydraulic steering helm in the UP series — a direct drop-in replacement for SeaStar® helms at a more accessible price point than the UP25FM or UP28FM. With a compact design, built-in lock valve, integral 1,000 PSI relief valve, and convenient front-of-dash fill, the UP20FM delivers reliable hydraulic steering performance for smaller outboard and sterndrive applications where the higher-output UP25 and UP28 series helms are more than required.
Compatible with Teleflex/SeaStar cylinders, hoses, and oil, the UP20FM integrates cleanly into existing SeaStar-compatible hydraulic steering systems.
Key Features
- UP20 Series — Entry-Level Output — Sized for smaller outboard and sterndrive applications; more cost-effective than UP25 or UP28 series helms
- Direct SeaStar® Drop-In Replacement — Same mounting footprint; no additional dash modifications required
- Compact Design — Low-profile front-mount configuration for clean dash installations
- Built-In Lock Valve — Provides positive rudder lock to hold steering position under load
- Integral Relief Valve — Over-pressure protection rated at 1,000 PSI
- 3/4" Tapered Aluminum Shaft — Accepts most standard marine steering wheels; note aluminum shaft vs. stainless steel on UP25FM and UP28FM
- Convenient Front-of-Dash Fill — Easy fluid access without removing the helm from the dash
- Easily Accessible Lock Valve and Shaft Seal — Simplified field servicing and seal replacement
- Adjustable Boss Fittings — Compatible with Uflex Kit OB, Kit OBSVS hose kits, and SeaStar hoses
- Relief Valve Pressure: 1,000 PSI
- Part Number: UP20FM | SKU: 216-UP20FM
Compatible Applications
- Direct replacement for SeaStar® front-mount hydraulic steering helms on smaller outboard and sterndrive applications
- Hydraulic steering systems where UP25 or UP28 series output is more than required
- Compatible with Teleflex/SeaStar cylinders, hoses, and hydraulic oil
- Compatible with Uflex Kit OB and Kit OBSVS hose kits
- For higher-output front-mount applications, see the Uflex UP25FM or UP28FM
- For tilt helm options, see the UP25TX52 or UP28TX52
Parts Desk Insights
Best Use Case: The UP20FM is the right helm for smaller outboard boats — typically in the 60–115 HP range — where a full UP25FM or UP28FM is more helm than the system needs and the lower price point of the UP20 series makes more sense. It retains the same SeaStar drop-in compatibility and front-of-dash fill convenience as the rest of the UP series, so it’s a straightforward replacement if you’re already running a SeaStar-compatible system on a smaller boat. One important distinction: the UP20FM uses an aluminum shaft rather than the stainless steel shaft found on the UP25FM and UP28FM — in saltwater environments, the aluminum shaft may require more attention to corrosion over time. If you’re replacing a helm and the original was a UP25FM or UP28FM, step up to match the original series rather than down to the UP20FM, as the output difference will result in more turns lock-to-lock. For high-performance applications, see the UP25FSVS SilverSteer™ Helm.
