Garmin GMR Fantom 56 — 5-Foot Open-Array Radar System
The GMR Fantom 56 is Garmin’s premium solid-state CHIRP radar system — a complete kit including the 5-foot open-array antenna and radar pedestal, ready to connect to a compatible Garmin GPSMAP chartplotter. It represents the top of Garmin’s open-array radar lineup, combining solid-state reliability with 60W of output power, MotionScope Doppler technology, and 72-nautical-mile range.
Solid-state CHIRP technology means no magnetron tube to warm up or eventually replace — the Fantom 56 is ready the moment you power it on, draws significantly less power than a comparable magnetron radar, and delivers superior target separation at close range. MotionScope uses Doppler processing to highlight moving targets in a distinct colour on the radar display, making it immediately clear which returns are vessels underway versus stationary objects — a meaningful safety advantage in busy shipping lanes, harbour approaches, and low-visibility conditions.
The 5-foot array balances beam sharpness and physical size, providing strong target resolution without the full footprint of a 6-foot array.
Key Specifications
- Antenna Length: 5 feet
- Transmit Power: 60W (solid-state)
- Maximum Range: 72 nautical miles
- Radar Technology: Solid-state CHIRP with MotionScope Doppler
- Key Advantages: Instant-on, low power draw, moving target highlighting, superior close-range discrimination
- Network Connection: Garmin Marine Network (Ethernet)
- Kit Contents: 5-foot open-array antenna and radar pedestal
- Compatible Displays: Garmin GPSMAP chartplotter series
- Part Number: K10-00012-18
Parts Desk Insights
Best Use Case: The GMR Fantom 56 is the right choice for serious offshore boaters, larger cruisers, and commercial operators who want the best available radar performance in a Garmin open-array system. The MotionScope Doppler feature is particularly valuable in high-traffic areas and poor visibility — instantly distinguishing moving vessels from stationary returns without having to interpret radar picture changes over time. Compared to the GMR 426 xHD2 complete kit, the Fantom 56 offers superior close-range target discrimination, instant-on operation, and lower power consumption at the cost of a higher purchase price. Compared to the GMR CHIRP 2104/2106 antenna-only units, this kit includes the pedestal and adds MotionScope Doppler — making it a complete, higher-capability system. Confirm your Garmin GPSMAP chartplotter supports the Garmin Marine Network and is compatible with the Fantom series before ordering. Ensure your radar arch or mast is rated for a 5-foot array’s weight and wind load.
Installation Note: Ships as two cartons — the 5-foot antenna in a long carton and the pedestal separately. Professional installation is strongly recommended at this system level. Use quality shielded Ethernet cable for all Garmin Marine Network connections.
Estimated Packaging: Two cartons — antenna approximately 66" × 12" × 8" (168 × 30 × 20 cm) and pedestal approximately 16" × 16" × 12" (41 × 41 × 30 cm), approx. 16 kg total shipped. Oversized freight shipping required.
