Garmin GPSMAP 8416xsv Chartplotter
The GPSMAP 8416xsv is Garmin’s flagship 16-inch full HD touchscreen chartplotter, built for serious offshore and coastal boaters who demand the largest, most capable primary display available in the GPSMAP lineup. With a full built-in sonar suite, preloaded BlueChart g3 and LakeVü g3 charts, and seamless Garmin Marine Network integration, it serves as the centrepiece of a complete glass helm system — combining navigation, sonar, radar, and autopilot control in a single large-format display.
Key Features
- 16" Full HD Touchscreen — Large, bright, sunlight-readable display with multi-touch capability; the largest display in the GPSMAP 8400 series
- Built-In CHIRP Sonar Suite — Supports CHIRP traditional sonar, CHIRP ClearVü, and CHIRP SideVü scanning sonar for detailed underwater imaging; transducer sold separately
- Panoptix LiveScope Compatible — Supports Garmin Panoptix LiveScope real-time scanning sonar for live underwater imaging around and below the vessel
- Preloaded BlueChart g3 & LakeVü g3 Charts — Comprehensive coastal and inland chart coverage included out of the box
- Garmin Marine Network — Integrates with Garmin radar, autopilot, VHF radio, instruments, and other networked devices for a fully unified helm system
- NMEA 2000 & NMEA 0183 — Full integration with third-party autopilots, VHF radios, instruments, and other onboard electronics
- Autopilot Ready — One-touch autopilot engagement and heading control when paired with a compatible Garmin GHP autopilot
- ActiveCaptain Integration — Connect via the ActiveCaptain app for chart updates, smart notifications, and community marina data
- Quickdraw Contours — Create and share personalised HD fishing maps with 1-foot contours
- Glass Helm Ready — Designed for multi-display glass helm installations; share data and views across multiple GPSMAP displays
Parts Desk Insights
Best Use Case: The GPSMAP 8416xsv is the primary display of choice for large offshore sport fishing vessels, cruising motoryachts, and serious passage-making sailboats (typically 40 ft+) where a large-format helm display is the centrepiece of a fully integrated Garmin navigation system. The 16-inch screen size makes it ideal as the primary helm display on vessels where multiple crew members need to view the chart simultaneously, or where the helm is positioned at a distance from the display. The built-in Panoptix LiveScope compatibility makes it particularly well-suited for serious anglers who want live sonar alongside full navigation capability. Pairs naturally with a Garmin GMR Fantom radar dome, GHP autopilot, GPS 24xd heading sensor, and VHF radio for a complete Garmin glass helm build.
Installation Notes: Flush-mount or bracket-mount installation. Requires 12V DC power. Garmin Marine Network cable required for radar and network device connections (sold separately). Sonar transducer sold separately — confirm transducer connector type (4-pin or 8-pin) and compatibility before ordering. For glass helm multi-display installations, plan network cabling between displays during installation.
Compatibility: Compatible with Garmin Marine Network devices. NMEA 2000 and NMEA 0183 compatible. Supports Garmin Panoptix LiveScope transducers. Works with Garmin GHP autopilots, GMR radar series, GPS 24xd heading sensor, and VHF radios. Supports microSD card for chart expansion and data transfer.
