Jabsco Green Polyurethane Ballast Pump Impeller Kit – 6303-0007-P

Product Description

The Jabsco 6303-0007-P is a six-blade green polyurethane impeller kit designed primarily for reversible wakeboard and ski-boat ballast pumps. Its flexible polyurethane construction, single-flat drive and plastic hub are engineered for rapid ballast-tank filling and draining while helping reduce unwanted water movement through the pump when the system is switched off. It is the current packaged replacement for the earlier 6303-0007 impeller.

Key Features

• Jabsco part number: 6303-0007-P
• Distributor SKU: 6-63030007P
• Green polyurethane construction
• Six flexible blades
• Impeller diameter: 2 inches / 50.8 mm
• Impeller width: 7/8 inch / approximately 22 mm
• Shaft diameter: 5/16 inch / approximately 8 mm
• Drive type: single-flat D-drive
• Plastic hub insert
• Reversible pump operation
• Kit includes the impeller, cover O-ring and installation lubricant
• UPC / GTIN: 671880588218

Pump Compatibility

The 6303-0007-P is documented for:

• Jabsco 18220-series Ballast Puppy pumps
• Jabsco 18220-1123
• Jabsco 18670-0123
• Jabsco 18670-6127
• Compatible Johnson Ultra Ballast pump applications requiring this same impeller specification

It is commonly used in automated ballast systems installed in wakeboard and ski boats. Always confirm the complete pump model before ordering.

Fitment Notice

Confirm that the original pump requires:

• A 2-inch diameter impeller
• 7/8-inch width
• 5/16-inch shaft
• Six blades
• Single-flat drive
• Green polyurethane construction

The 6303 family includes impellers with similar dimensions but different compounds. Match the full impeller number and material rather than relying only on colour or diameter.

When This Part Needs Replacement

Replace the impeller when:

• The ballast tank fills or drains more slowly than normal
• The pump runs but moves little or no water
• Water enters or leaves the ballast tank while the pump is off
• The pump struggles to reverse direction
• The blades are cracked, distorted, torn or permanently folded
• The hub slips on the motor shaft
• The pump has operated dry
• Preventive ballast-system service is due

Wear at the vane tips can reduce pump output and may also prevent the impeller from sealing effectively inside the pump chamber.

Installation Notes

• Isolate electrical power to the ballast pump.
• Remove the end-cover screws, cover and existing O-ring.
• Pull the old impeller straight from the motor shaft.
• Inspect the pump chamber and cover for debris or scoring.
• Apply the supplied glycerine lubricant to the impeller bore and blades.
• Align the flat inside the hub with the flat on the motor shaft.
• Install the impeller using a gentle rotating motion.
• Fit the new O-ring and reinstall the cover.
• Test the pump in both fill and drain directions.
• Do not operate the pump dry for extended periods.

Jabsco’s installation guidance specifies aligning the flat in the impeller with the motor-shaft flat before installing it with a rotary motion.

Alternate / Related Part Numbers

• Current packaged number: 6303-0007-P
• Earlier number: 6303-0007
• Distributor SKU: 6-63030007P
• Compact format: 63030007P
• Also catalogued as: 06303-0007-P
• Related reference: 6303-0107-P
• Bulk-pack number: 6303-0007-24
• UPC / GTIN: 671880588218

Parts Desk Insight

This is the premium green ballast-pump impeller, not a standard neoprene engine-cooling impeller. The most reliable fitment checks are the 18220-series pump number, 5/16-inch single-flat shaft and 7/8-inch impeller width.
