Hino Oil Filter Element Set S1560-71630
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
The Hino S1560-71630 is a genuine replacement lubricating-oil filter element set for select Hino diesel-engine applications. Installed inside the engine's reusable oil-filter housing, the element removes soot, metallic wear particles and other contaminants from circulating oil to help protect bearings, journals and other lubricated engine components.
This product is supplied as one OEM element set and is also identified without punctuation as S156071630. Available catalogue data lists an approximate product weight of 0.23–0.27 kg.
Key Features
- Genuine Hino replacement oil-filter element set
- Cartridge-style service component for a reusable filter housing
- Designed for engine-lubrication filtration
- Helps remove soot, wear particles and oil-system contamination
- Manufactured to the original Hino application specification
- Supplied as one element set
- Hino part number: S1560-71630
- Compact part-number format: S156071630
Engine Compatibility
The S1560-71630 is intended for select Hino diesel engines and equipment specifically calling for this OEM filter-element number.
Hino filter applications can vary according to:
- Engine family
- Production year
- Vehicle or equipment model
- Chassis number
- Filter-housing design
- Industrial or marine conversion
Use this element only where the applicable Hino parts catalogue, engine manual or existing filter identification confirms S1560-71630.
Serial Number Fitment Notice
Confirm the complete engine model and serial number before ordering. For vehicle-based applications, the chassis or VIN information may also be required to verify the correct filter element.
Hino uses numerous visually similar S1560-series oil-filter elements. Similar diameter, length or appearance does not confirm compatibility because the internal opening, sealing arrangement and filtration specification may differ.
The user-supplied number S1560-7163 appears to be a shortened presentation of the complete Hino number S1560-71630.
When This Part Needs Replacement
Replace the oil-filter element whenever the engine oil is changed or at the interval specified in the applicable Hino maintenance schedule.
Earlier replacement may be appropriate following:
- Fuel, coolant, water or debris contamination
- Internal engine repairs
- Abnormal oil-pressure conditions
- Extended heavy-load operation
- Long periods of seasonal storage
- Excessive soot or sludge accumulation
Do not reuse an oil-soaked or contaminated cartridge element.
Installation Notes
Shut down the engine, allow it to cool and follow the applicable Hino service procedure before opening the oil-filter housing.
- Drain or isolate the filter housing as required.
- Remove the housing cover and old filter element.
- Clean sludge and debris from the reusable housing.
- Inspect the centre tube, spring, retaining hardware and sealing surfaces.
- Replace housing seals or O-rings whenever specified by the service manual.
- Install the new element in the same orientation as the removed cartridge.
- Reassemble and tighten the housing to the specified torque.
- Refill the engine with the correct oil.
- Start the engine and inspect the housing for leaks.
- Shut down the engine, allow the oil to settle and recheck the oil level.
Alternate/Superseded Part Numbers
Known number formats include:
- S1560-71630
- S156071630
No alternate or superseding part number should be assumed without checking the current Hino parts catalogue for the exact engine or chassis application.
Parts Desk Insight
The easy mistake with Hino cartridge filters is matching them by appearance. Confirming the complete S1560-71630 number and the engine or chassis information is the safest way to avoid installing an element with the wrong sealing or internal dimensions.
