Jabsco 6-189580001P / 18958-0001-P Neoprene Impeller Kit – Sherwood P17 Pumps
The Jabsco 18958-0001-P is a heavy-duty 12-blade neoprene flexible impeller kit used in large marine engine raw-water cooling pumps. It is a recognised replacement for the Sherwood 17000K and is commonly associated with Sherwood P17-series pumps installed on Caterpillar, Cummins and John Deere marine diesel engines. The impeller has a brass keyed hub and Profile GG configuration.
Key Features
- Jabsco part number: 18958-0001-P
- Land 'N' Sea SKU: 6-189580001P
- Twelve flexible blades
- Neoprene construction
- Brass hub insert
- Keyed shaft drive
- Impeller profile: GG
- Diameter: approximately 82.5–84 mm
- Width: approximately 73–74 mm
- Shaft bore: approximately 20–21 mm
- Designed for engine cooling and fresh- or saltwater pumping
- UPC / GTIN: 671880588201
Pump Compatibility
The 18958-0001-P cross-references the Sherwood 17000K impeller used in numerous P17-series pumps, including documented applications such as:
- P1710 and P1710X
- P1716 and P1716B
- P1719 and P1719F
- P1722 and P1722B
- P1726 and P1726X
- P1730 and P1730F
- P1731F
- P1732 and P1732X
- P176 and P176X
Pump suffixes and repair-kit contents can vary, so confirm the complete pump model before ordering.
Engine Compatibility
Commonly documented engine applications include compatible raw-water pumps on:
Caterpillar
- 3116
- 3126 and 3126B
- 3208
- Selected C7 and C9 installations
Cummins
- B-Series marine engines, including selected 6B 300 hp applications
- C-Series marine engines
- Selected 6CTA 8.3 marine applications
John Deere
- Selected 6076 marine engine cooling pumps
Compatibility depends on the installed Sherwood pump and should be verified by pump number or original OEM impeller reference rather than engine model alone.
Fitment Notice
Before ordering, confirm that the original impeller requires:
- Twelve blades
- Approximately 83–84 mm outside diameter
- Approximately 73 mm width
- Keyed brass hub
- Approximately 20 mm shaft bore
- Sherwood 17000K or equivalent specification
Published catalogues contain minor differences in rounded imperial dimensions, but the consistent identifying specifications are the 12-blade Profile GG design, roughly 83 × 74 mm body and keyed brass hub.
When This Part Needs Replacement
Replace the impeller when:
- Raw-water flow or exhaust discharge decreases
- Engine temperature rises above normal
- The pump struggles to prime
- Vanes become cracked, hardened or permanently curved
- Blade tips are torn or missing
- The brass hub or keyway becomes worn
- The pump has operated dry
- Scheduled annual cooling-system service is due
Preventive replacement is recommended because a failed raw-water impeller can quickly cause engine overheating.
Installation Notes
- Stop the engine and isolate its starting system.
- Close the raw-water intake seacock.
- Remove the pump end cover and sealing component.
- Use an appropriately sized impeller puller to extract the old impeller.
- Avoid prying against the pump face with a screwdriver.
- Retrieve missing vane fragments from hoses, coolers and heat exchangers.
- Inspect the pump bore, cam, cover plate, shaft and drive key.
- Lubricate the new impeller before installation.
- Align the brass-hub keyway with the shaft key.
- Install the correct O-ring or gasket for the pump model.
- Reopen the seacock and confirm strong water flow immediately after startup.
Do not run the pump dry beyond the brief period needed to establish prime.
Alternate / Superseded Part Numbers
- Jabsco: 18958-0001-P
- Earlier Jabsco number: 18958-0001
- Land 'N' Sea SKU: 6-189580001P
- Compact format: 189580001P
- Sherwood: 17000K
- Sherwood related reference: 21931
- Johnson Pump: 09-704BT-1
- Caterpillar: 1W5664, 7E0321
- Cummins: 3802444, 3897337, 3916852, 3925236
- John Deere: RE49896
- UPC / GTIN: 671880588201
Parts Desk Insight
This is the large replacement impeller associated with the Sherwood 17000K and P17 pump family. The critical checks are the approximately 83 mm diameter, 73 mm width, 12 blades and keyed brass hub. Because P17 pumps use different repair kits depending on the exact suffix, always verify the complete pump model before selecting additional seals or service components.
