Lowrance 00015445002 Reversible Hydraulic Gear Pump-3 – 12V Autopilot Pump
The Lowrance Pump-3 is a 12V reversible hydraulic gear pump designed for integration with Lowrance autopilot systems. It delivers precise, responsive hydraulic steering control for mid-to-large displacement cylinders, covering a cylinder displacement range of 160–550 cc (9.8–33.5 cu. in.). Compatible with the Lowrance SteadySteer autopilot system and requires the NAC-3 or AC42 autopilot computer for operation.
Key Features
- Reversible hydraulic gear pump — 12V DC operation
- Cylinder displacement range: 160–550 cc (9.8–33.5 cu. in.)
- O-Ring Boss (ORB) hydraulic connections for leak-free installation
- Includes 3 x ORB-5 to 9/16" UNF fittings
- SteadySteer compatible
- Requires NAC-3 or AC42 autopilot computer (sold separately)
- Part number: 00015445002
Parts Desk Insights
Best use case: The Pump-3 is the correct choice for vessels with mid-to-large hydraulic steering cylinders in the 160–550 cc displacement range — typical of larger outboard-powered boats, inboard cruisers, and sportfishers with full hydraulic helm systems. Always verify your cylinder’s displacement before selecting a pump; using an undersized or oversized pump will result in poor autopilot performance. If your cylinder displacement falls below 160 cc, see the Lowrance Pump-2 (80–250 cc). For larger cylinders above 550 cc, see the Lowrance Pump-4 (290–960 cc). Note that this pump requires the NAC-3 or AC42 autopilot computer, which must be purchased separately.
Specifications
- Part number: 00015445002
- Pump designation: Pump-3
- Voltage: 12V DC
- Cylinder displacement: 160–550 cc (9.8–33.5 cu. in.)
- Connection type: O-Ring Boss (ORB)
- Included fittings: 3 x ORB-5 to 9/16" UNF
- Compatibility: Lowrance SteadySteer autopilot systems
- Required component: NAC-3 or AC42 autopilot computer (not included)
