Mercury MerCruiser Bravo Sterndrive Cable Bonding Kit 847062A1
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Part Details
- Part Number: 847062A1
- Brand: Mercury Marine
- Product Type: Cable Bonding Kit
- GTIN / Barcode: 745061409644
- System: Sterndrive electrical continuity and corrosion-protection circuit
- Diagram Position: Bonding / continuity locations within Bravo X/XR transom, steering, sterndrive housing, and SSM VII drive assemblies
- Quantity Required: Varies by assembly — some continuity diagrams call for up to three kits; SSM assemblies may require one at a specific location. Always confirm from your parts diagram.
Compatible Applications
Verify fitment by drive model, transom assembly type, and drive serial number before ordering. Documented applications include:
- Mercury MerCruiser Bravo One
- Mercury MerCruiser Bravo X
- Mercury MerCruiser Bravo XR
- Mercury MerCruiser Bravo XR SportMaster (serial range 0M052945 through 0M906877 and later)
- Bravo XR One (serial range 0L914990 through 0W239999 and 0W240000 and up)
- Bravo-family integrated and standard transom systems
- SSM VII wet-sump drive assemblies
- Selected Mercury Racing / high-performance steering and transom configurations
Mercury uses 847062A1 in several different bonding locations across these drives. Required quantity varies — confirm by exact drive serial number and parts diagram.
Kit Contents
This kit contains the bonding cable(s) and associated hardware needed for the bonding locations specified in the applicable Mercury parts diagram. Contents vary by assembly — refer to the diagram for your specific drive and serial range.
Related Parts
- Mercury MerCruiser Quicksilver Continuity Kit 99940A2 — related continuity kit frequently used alongside 847062A1
- Bonding plates 847022 and 847035 — associated bonding hardware on selected Bravo and SSM VII assemblies (search by part number)
Dimensions & Weight
- Estimated weight: approx. 0.25 lb (0.113 kg)
- Estimated packed dimensions: approx. 8.00 in. × 4.00 in. × 2.00 in. (20.32 cm × 10.16 cm × 5.08 cm)
When to Replace
Replace the bonding cable kit if inspection reveals any of the following:
- Broken or missing bonding straps
- Corroded or damaged cable terminals
- Frayed or deteriorated conductors
- Loose attachment points
- Poor electrical continuity between bonded components
- Physical damage during steering, transom, or sterndrive service
A failed bonding connection can leave individual metal components outside the drive’s corrosion-protection circuit, accelerating galvanic corrosion on unprotected parts.
Service Interval
Inspect bonding cables during any sterndrive, transom, or steering service that involves removal of bonded components. Replace immediately if any cable or terminal shows damage, corrosion, or loss of continuity. Follow Mercury MerCruiser service procedures for corrosion-protection and continuity testing after installation.
Installation Notes
- Clean all bonding attachment points to bare conductive metal as specified
- Remove corrosion from beneath cable terminals before installing
- Inspect related bonding plates and continuity hardware at the same time
- Verify all cable terminals are fully secured after installation
- Confirm electrical continuity through all bonded drive components after assembly
- Follow the applicable Mercury MerCruiser service manual for corrosion-protection and continuity testing steps
Parts Desk Insights
Bonding cables are one of the most overlooked items during sterndrive service because they have no moving parts and don’t affect how the drive operates mechanically. Their job is electrical: keeping separate sterndrive and transom components at the same electrical potential so the corrosion-protection system works as designed. The most common issue is customers ordering only one kit when their specific assembly calls for two or three — always check the quantity in the parts diagram for your drive serial number. If one bonding strap is damaged or corroded, it’s worth inspecting the entire continuity system at the same time.
Technical FAQ
Q: What does the bonding kit actually do?
A: It electrically connects separate metallic drive and transom components so they share the same corrosion-protection circuit. Without it, isolated metal parts can corrode significantly faster.
Q: How many kits do I need?
A: It depends on your specific drive assembly — some diagrams call for up to three 847062A1 kits. Check the parts diagram for your drive model and serial number for the exact quantity.
Q: Is this the same as an anode kit?
A: No. Anodes are sacrificial zinc or aluminum components. This is a bonding/continuity kit — it ensures all metal parts are electrically connected so the anodes can protect the entire system.
Q: Does this fit all Bravo drives?
A: It is used across several Bravo variants but fitment depends on the specific transom assembly, steering configuration, and drive serial number. Confirm against the Mercury parts diagram for your drive before ordering.
