Mercury Quicksilver Carburetor Diaphragm Kit — 857005A1
| Part Number | 857005A1 | Mercury Catalog: 21-857005A1 |
| Brand | Mercury Marine / Quicksilver |
| Official Product Type | Carburetor Diaphragm Repair Kit |
| Kit Contents | 12-piece set — fuel-pump diaphragms, gaskets, check valves, spring, cap, and screws |
| System | Fuel / Carburetor |
| Engine Family | Mercury & Mariner 2-stroke outboards |
| GTIN / Barcode | 745061440685 |
Compatible Applications
Mercury officially rates 857005A1 for selected 30–65 HP Mercury and Mariner 2-stroke outboards. Exact fitment depends on carburetor and fuel-pump configuration. Confirm by engine horsepower, model year, serial number, and parts diagram before ordering.
- 30 HP Mercury & Mariner 2-stroke outboards (selected models)
- 40 HP Mercury & Mariner 2-stroke outboards (selected models)
- 50 HP Mercury & Mariner 2-stroke outboards (selected models)
- 60 HP Mercury & Mariner 2-stroke outboards (selected models)
- 65 HP Mercury & Mariner 2-stroke outboards (selected models)
Serial Number & Diagram Fitment
Mercury used multiple diaphragm-kit configurations across similar 2-stroke outboards. Always verify by engine model, serial number, and the carburetor/fuel-pump parts diagram — not by appearance alone. If you have your serial number, contact us and we will confirm fitment before you order.
Superseded / Legacy Part Numbers
857005A1 is the current replacement for the following earlier kit numbers:
- 42990A8
- 42990A10
- 42990A11
Additional 42990A-series numbers may also cross to 857005A1 depending on application.
When to Replace the Diaphragm Assembly
Consider a full rebuild when you notice any of the following:
- Hard starting or failure to start
- Fuel starvation at speed
- Hesitation or stumble during acceleration
- Poor high-speed fuel delivery
- Irregular idle
- Loss of power under load
- Fuel leakage at the diaphragm section
- Hardened, torn, or distorted diaphragm material
Installation Notes
- Clean the carburetor body thoroughly before disassembly
- Note the order and orientation of diaphragms, gaskets, and check valves
- Replace the entire soft-parts set — do not reuse hardened or compressed components
- Inspect mating surfaces for corrosion or distortion before reassembly
- Inspect fuel hoses and connections while the assembly is apart
- Follow the Mercury service manual for your specific engine serial range
Related Parts
- Mercury Carburetor Fuel Pump Diaphragm 16275
- Mercury MerCruiser Quicksilver Carburetor Fuel Pump Diaphragm 16325
- Mercury Carburetor Fuel Pump Cover Gasket 27-16274
- Mercury MerCruiser Quicksilver Diaphragm Kit 55278A1
Parts Desk Insights
This is the kit to reach for when a 30–65 HP 2-stroke Mercury or Mariner is showing fuel-delivery symptoms — hard starting, hesitation, or lean-running conditions are the most common complaints we see linked to a worn diaphragm on these engines. Because Mercury supplies the complete 12-piece soft-parts set together, a full rebuild is more reliable than sourcing individual components separately. Match by the engine parts diagram first, then confirm with the serial number — the same horsepower range can carry different carburetor assemblies across production years.
