Mercury MerCruiser Bearing Carrier Seal – Inside, 26-14077 | MR, Alpha One, Alpha One Gen II
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Mercury MerCruiser Quicksilver 26-14077 / 14077 is a genuine OEM bearing carrier oil seal used at the propeller-shaft bearing carrier on select MerCruiser sterndrives. Mercury Marine specifically lists this seal for MR, Alpha One, Alpha One SS, and Alpha One Gen II drives. In applicable gearcase diagrams, 14077 is identified as the inside bearing-carrier seal, helping retain gear lubricant and protect the gearcase from water intrusion around the propeller shaft.
Key Features
- Genuine Mercury Marine / Quicksilver OEM seal
- Mercury part number 26-14077 / 14077
- Official Mercury description: Bearing Carrier Seal
- Installed as the inside oil seal in applicable propeller-shaft bearing carrier assemblies
- Fits select MR, Alpha One, Alpha One SS, and Alpha One Gen II sterndrives
- Mercury package quantity: 1 seal
- GTIN / UPC reference: 745061080034
- Approximate packaged dimensions: 1.58 × 1.58 × 0.25 in
- Approximate packaged weight: 0.02 lb
Application Compatibility
Confirmed Mercury Marine sterndrive applications include:
- MerCruiser MR
- MerCruiser Alpha One
- MerCruiser Alpha One SS
- MerCruiser Alpha One Gen II
The seal appears within the propeller-shaft / bearing-carrier section of the gear housing. Mercury also uses 14077 in selected outboard gearcase applications, so the exact drive or gearcase parts diagram should be checked before ordering.
Fitment Notice
Do not confuse 26-14077 with the neighboring outside bearing-carrier seal. In applicable Mercury gearcase diagrams:
- 14077 / 26-14077 – Inside seal
- 8M0204670 – Outside seal, replacing earlier 26-76868
These seals occupy different positions in the bearing carrier and should not be treated as interchangeable. Confirm the sterndrive model, serial number, and gearcase diagram before ordering.
When This Part Needs Replacement
Replace the seal when there is gear lubricant leaking around the propeller shaft, evidence of water entering the gearcase, visible seal damage, hardened or deteriorated sealing lips, or whenever bearing-carrier service requires removal of the existing seal.
Milky or emulsified gear lubricant can indicate water intrusion and should prompt inspection of the complete propeller-shaft sealing arrangement.
Installation Notes
Inspect the propeller shaft where the seal lip rides for scoring, corrosion, fishing-line damage, or excessive wear before installing a new seal. Also inspect the bearing carrier and the adjoining outside seal while the assembly is apart.
Install the seal in the correct orientation and depth specified in the applicable Mercury service manual. Avoid damaging the sealing lip during installation and pressure-test the gearcase after service when required by the Mercury procedure.
Alternate / Superseded Part Numbers
- 14077 – Current Mercury / Quicksilver bearing carrier seal
- 26-14077 – Mercury formatted part number
- Sierra 18-2077 – Aftermarket cross-reference
- GLM 85130 – Aftermarket cross-reference
- Mallory 9-76119 – Aftermarket cross-reference
Important: 8M0204670 is not the direct replacement for 14077 in applicable MerCruiser bearing-carrier diagrams. It is shown separately as the outside seal, while 14077 is the inside seal.
Parts Desk Insights
There are normally two seal positions around the propeller shaft bearing carrier, and this is where parts can easily get mixed up. 26-14077 is the inside seal; 8M0204670 is the outside seal on applicable gearcases. If gear oil is already contaminated with water, inspect both seals and the propeller-shaft sealing surface while the carrier is apart.
Browse all Mercury MerCruiser / Quicksilver Gaskets & Seals or MerCruiser Marine Engine Parts.
