Volvo Penta Gear Shift Actuator 22663814 | OEM | DPH / DPR Sterndrive | D4 / D6
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Part Details
- Part Number: 22663814
- Brand: Volvo Penta (Genuine OEM)
- Official Product Type: Gear Shift Actuator
- Supersedes: 21505553, 21146097, 3817496, 3817124
- Replaced By: No further supersession — 22663814 is the current active number
- System: Sterndrive Shift Control — DPH / DPR
- Diagram Position: Item 1 in DPH-E Shift Actuator Assembly
- Quantity Required: 1 per drive
- Weight (approx.): 1.5 kg / 3.3 lb
What This Part Does
The gear shift actuator mechanically operates the gear-shift mechanism in response to helm control commands, engaging forward, neutral, and reverse in the DPH or DPR sterndrive. In documented DPH-E shift assemblies, 22663814 is Item 1 and works with the surrounding linkage, adapter, bracket, and fastener hardware to complete the shift assembly. The actuator is a precision component — correct installation and EVC calibration are required after replacement.
Compatible Applications
Documented fitment includes selected Volvo Penta D4 and D6 diesel sterndrive packages equipped with DPH or DPR drives. Always confirm by complete engine model, sterndrive model, and serial number before ordering.
- Volvo Penta D4-210A-A / D4-210A-B
- Volvo Penta D4-225A-C / D / E
- Volvo Penta D4-260A-A / B / C / D / E
- Volvo Penta D4-300A-A / C / D / E
- Volvo Penta D6-280A-A / B / C / E
- Volvo Penta D6-310A-A / B / C / E
- Volvo Penta D6-330A-B / C / E
- Volvo Penta D6-350A-A / B
- Volvo Penta D6-370A-B / C / E
- Volvo Penta D6-400A-E
- Drive types: DPH-A, DPH-C, DPH-D, DPH-D1, DPH-E
- Drive types: DPR-A, DPR-B, DPR-C, DPR-D
Serial Number & Fitment Notice
Volvo Penta revised the DPH/DPR shift system across several production generations. Serial number confirmation is essential — do not select by engine horsepower or drive family alone. The strongest fitment check is locating 22663814 as Item 1 in the exact Volvo Penta DPH-E shift actuator assembly diagram for the drive being serviced.
Superseded Part Numbers
- 22663814 — current number
- 21505553 — previous number, superseded by 22663814
- 21146097 — earlier number, superseded by 22663814
- 3817496 — earlier number, superseded by 22663814
- 3817124 — earlier number, superseded by 22663814
When This Part Needs Replacement
Replace the gear shift actuator if any of the following are present:
- Failure to engage forward or reverse gear
- Intermittent or delayed gear engagement
- Incomplete or inconsistent gear selection
- Excessive play or binding in the shift mechanism
- Shift-related EVC fault messages that persist after linkage and harness inspection
- Mechanical damage or corrosion on the actuator body
Before replacing the actuator, inspect the surrounding shift linkage, adapter, bracket, connectors, wiring, and EVC control system. A linkage fault or electrical issue can produce identical symptoms to actuator failure.
Installation Notes
In the DPH-E shift assembly, 22663814 works alongside the following components — inspect all of them for wear, corrosion, binding, or looseness while the shift system is open:
- Actuator 22583980
- Adapter 3850941
- Washer 940191
- Split pin 17253
- Washer 819068
- Bracket 21471054
- Six-point socket screw 973155
- After installation, verify correct forward, neutral, and reverse engagement before returning to service
- Complete any required EVC shift setup or calibration per the Volvo Penta service documentation for your drive model
- Refer to the applicable Volvo Penta DPH/DPR workshop manual for torque specifications and setup procedures
Related Parts
- Browse Volvo Penta Drive Components for additional DPH / DPR shift and sterndrive service parts
- Browse Volvo Penta Marine Engine Parts for the full Volvo Penta catalog
Parts Desk Insights
Best use case: This actuator is the right part when the DPH or DPR sterndrive is confirmed to have failed shift engagement and the EVC fault codes or physical inspection points specifically to the actuator rather than the surrounding linkage, cables, or control system. Because of the price point, a thorough diagnosis — including inspection of the shift linkage, connectors, and EVC calibration status — before ordering is strongly recommended.
Common issue: This is the gear-shift actuator, not the trim or steering actuator. On DPH/DPR systems they are physically distinct but can be confused when ordering by general description. The most reliable identification method is the Volvo Penta shift assembly diagram for your specific drive model and serial number — confirm 22663814 appears as Item 1 in that diagram before ordering. Ordering based on drive family alone without serial number verification is the most common mistake with this part.
