PSS Dripless Shaft Seal — 1-3/8" Shaft × 2-1/4" Stern Tube
The PSS 02-138-214 is a Type A mechanical face-type dripless shaft seal for inboard vessels running a 1-3/8" propeller shaft and a 2-1/4" to 2-3/8" stern tube. A stationary carbon-graphite flange presses against a rotating stainless-steel rotor to form a positive seal — no drip, no packing adjustment, no shaft wear from a conventional stuffing box.
Key Specifications
- Shaft diameter: 1-3/8"
- Stern tube (shaft log) OD: 2-1/4" to 2-3/8"
- Seal type: PSS Type A mechanical face seal
- Sealing flange: carbon-graphite
- Rotor: stainless steel (approx. 2.875" OD)
- Compression maintained by bellows
- Overall length: approx. 7.5"
- Required bellows compression: approx. 3/4"
- Stern-tube cuff length: approx. 1.5"
- Part number: 02-138-214 / 02138214
- UPC: 839662007405
Compatible Applications
- Inboard marine propulsion systems with a 1-3/8" propeller shaft
- Stern tubes measuring 2-1/4" to 2-3/8" OD at the bellows connection point
- Both shaft diameter and stern-tube diameter must be confirmed before ordering — do not select by shaft size alone
When to Replace
- Bellows shows aging, cracking, or deterioration (below-waterline component — inspect regularly)
- Sealing faces are damaged or no longer seat correctly
- Persistent leakage develops at the seal interface
- Hose connections, clamps, or rotor set screws show corrosion or looseness
Installation Notes
- Maintain specified bellows compression and correct stainless-steel rotor position per current PSS instructions
- Clean and inspect carbon and stainless sealing faces before assembly
- Secure all clamps and set screws; configure vent or water-feed connection as required
- Verify at least 7.5" of clear shaft space is available before the coupler or cutlass bearing
Alternate & Cross-Reference Part Numbers
- 02-138-214
- 02138214
- Distributor ref: 730-02138214
- Maintenance kit: 07-138-214R
- Shaft retention collar: 07-SRC-138
- UPC: 839662007405
Other PSS Shaft Seal Sizes
- PSS 02078112 — 7/8" Shaft
- PSS 02-100-112 — 1" Shaft x 1-1/2" Stern Tube
- PSS 02-114-214 — 1-1/4" Shaft x 2-1/4" Stern Tube
- PSS 02-212-312 — 2-1/2" Shaft x 3-1/2" Stern Tube
Parts Desk Insights
The 02-138-214 shares the same 2-1/4" to 2-3/8" stern tube range as the 1-1/4" 02-114-214 — the only difference is the shaft bore. If you’re unsure which you have, measure the shaft with calipers rather than relying on the boat’s documentation, as 1-1/4" and 1-3/8" shafts are easy to confuse by eye. Measuring the shaft log OD before ordering is equally important to avoid a seal that fits the shaft but not the stern tube.
