Hella Seahawk 470 LED Light Bar — Spread Lens, 30°×60° Beam, 20.86" (958130601)
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Hella Seahawk 470 — Spread Lens LED Light Bar, 30°×60° Beam (958130601)
The Hella Seahawk 470 Spread Lens delivers a 30°×60° beam pattern — the same 30° vertical height as the Spot, but with double the horizontal width at 60°. The result is a broad, even wash of light that prioritizes lateral visibility over long-range center punch, making it highly effective for close-range situational awareness in confined or busy waterways.
Built on the Seahawk 470 platform with a corrosion-proof housing, Grilamid® UV-resistant lens, and polished 316 stainless steel bracket. The adjustable mounting system supports both upright and pendant installation. Pre-wired with 2.5m of bare-wire cable. IP67-rated and backed by a 5-year warranty.
Specifications
- Model: Seahawk 470
- Lens type: Spread
- Beam angle: 30° × 60° (H × W)
- Connector: Standard (bare wire, 2.5m cable included)
- Dimensions: 20.86" L × 1.73" H
- Power draw: 36W (high beam), 18W (Combi mode)
- Bracket: Polished 316 stainless steel
- Lens material: Grilamid® (UV resistant)
- Housing: Corrosion-proof
- Waterproof rating: IP67
- Mount options: Upright or pendant
- Warranty: 5 years
- SKU: 265-958130601
Best Use Case
The Spread Lens is the right choice when wide lateral visibility matters more than long-range throw — maneuvering through tight marina berths, docking in low-light conditions, or illuminating a broad deck or cockpit area at close range. For both reach and width from a single bar, the Combi is worth considering. For maximum long-range illumination in a narrow beam, the Spot Lens is the better fit.
Also Consider
- Hella Seahawk 470 — Spread Lens (958130611) — alternate Spread Lens configuration at the same spec
- Hella Seahawk 470 — Wide Spread Diffused — even broader diffused coverage for deck and cockpit flood lighting
- Hella Seahawk 470 — Combi (Spread & Spot) — dual-beam: reach and width in one bar
- Hella Seahawk 470 — Spot Lens (30°×30°) — tighter beam for longer-range illumination
- Browse all Marine Lighting
Parts Desk Insights
SKU 265-958130601 and SKU 265-958130611 are both Seahawk 470 Spread Lens models at the same price point — the distinction between these two SKUs should be confirmed with the supplier, as it may relate to bracket configuration, regional packaging, or a minor hardware revision. If a customer is choosing between the two, either is appropriate unless a specific mounting configuration is required. The Spread (30°×60°) vs. Wide Spread Diffused distinction is worth communicating: the Spread is directional with a defined beam shape, while the Wide Spread Diffused scatters light more broadly for pure flood applications. As with all Seahawk 470 models, this is not a COLREGS-compliant navigation light. The 5-year warranty and IP67 rating are strong selling points vs. competing brands.
