Hella Seahawk 470 — Wide Spread Diffused LED Light Bar (958130501)
The Hella Seahawk 470 Wide Spread Diffused is built for broad, comfortable area illumination rather than directional reach. Its diffused lens scatters light evenly across a wide field with no hot spot or harsh center punch — delivering soft, glare-reduced output that's ideal for cockpit, deck, and work-area lighting where you want to see everything around you without blinding crew or other boaters nearby.
Built on the Seahawk 470 platform with a corrosion-proof housing, Grilamid® UV-resistant lens, and polished 316 stainless steel bracket. The adjustable mounting system supports both upright and pendant installation. Pre-wired with 2.5m of bare-wire cable. IP67-rated and backed by a 5-year warranty.
Specifications
- Model: Seahawk 470
- Lens type: Wide Spread Diffused
- Output character: Broad, soft, diffused flood — no defined beam angle
- Connector: Standard (bare wire, 2.5m cable included)
- Dimensions: 20.86" L × 1.73" H
- Power draw: 36W (high beam), 18W (Combi mode)
- Bracket: Polished 316 stainless steel
- Lens material: Grilamid® (UV resistant)
- Housing: Corrosion-proof
- Waterproof rating: IP67
- Mount options: Upright or pendant
- Warranty: 5 years
- SKU: 265-958130501
Best Use Case
The Wide Spread Diffused is the right choice for cockpit and deck flood lighting where broad, comfortable illumination matters more than reach or directionality — entertaining at anchor, working on deck at night, or lighting a swim platform. The diffused output reduces glare for crew and passengers, making it significantly more comfortable for close-range use than a spot or spread beam. It is not suited to navigation or long-range illumination tasks; for those applications, the Spot or Combi lenses are the better fit.
Also Consider
- Hella Seahawk 470 — Wide Spread Diffused (958130511) — alternate Wide Spread Diffused configuration at the same spec
- Hella Seahawk 470 — Spread Lens (30°×60°) — directional wide-angle beam for maneuvering and docking
- Hella Seahawk 470 — Combi (Spread & Spot) — dual-beam: reach and width in one bar
- Hella Seahawk 470 — Spot Lens (30°×30°) — long-range directional illumination
- Browse all Marine Lighting
Parts Desk Insights
SKU 265-958130501 and SKU 265-958130511 are both Seahawk 470 Wide Spread Diffused models at the same price — the distinction should be confirmed with the supplier, as it may relate to bracket configuration, regional packaging, or a minor hardware revision. The key customer education point for the Wide Spread Diffused is the difference between diffused and directional output: diffused means no defined beam angle and soft, scattered light — it will not throw light at distance the way a Spot or Spread lens will. Customers sometimes order this expecting long-range performance; confirm their use case before recommending. As with all Seahawk 470 models, this is not a COLREGS-compliant navigation light. The 5-year warranty and IP67 rating are strong selling points vs. competing brands.
