Hella Seahawk 470 — Wide Spread Diffused LED Light Bar (958130511)
The Hella Seahawk 470 Wide Spread Diffused is the flood-lighting specialist of the Seahawk 470 lineup. Where the Spot and Spread lenses deliver defined, directional beams, the Wide Spread Diffused scatters light broadly across a wide area with soft, even illumination — no hot spot, no harsh center punch. The result is comfortable, glare-reduced light that's ideal for cockpit, deck, and work-area applications where you want to see everything around you without blinding crew or other boaters.
Built on the same Seahawk 470 platform with a corrosion-proof housing, Grilamid® UV-resistant lens, and polished 316 stainless steel bracket. The adjustable mounting system supports both upright and pendant installation. Pre-wired with 2.5m of bare-wire cable. IP67-rated and backed by a 5-year warranty.
Specifications
- Model: Seahawk 470
- Lens type: Wide Spread Diffused
- Output character: Broad, soft, diffused flood — no defined beam angle
- Connector: Standard (bare wire, 2.5m cable included)
- Dimensions: 20.86" L × 1.73" H
- Power draw: 36W (high beam), 18W (Combi mode)
- Bracket: Polished 316 stainless steel
- Lens material: Grilamid® (UV resistant)
- Housing: Corrosion-proof
- Waterproof rating: IP67
- Mount options: Upright or pendant
- Warranty: 5 years
- SKU: 265-958130511
Best Use Case
The Wide Spread Diffused is the right choice for cockpit and deck flood lighting where broad, comfortable illumination matters more than reach or directionality — entertaining at anchor, working on deck at night, or lighting a swim platform. The diffused output reduces glare for crew and passengers, making it significantly more comfortable for close-range use than a spot or spread beam. It is not suited to navigation or long-range illumination tasks; for those applications, the Spot or Combi lenses are the better fit.
Also Consider
- Hella Seahawk 470 — Wide Spread Diffused (958130501) — alternate Wide Spread Diffused configuration at the same spec
- Hella Seahawk 470 — Spread Lens (30°×60°) — directional wide-angle beam for maneuvering and docking
- Hella Seahawk 470 — Combi (Spread & Spot) — dual-beam: reach and width in one bar
- Hella Seahawk 470 — Spot Lens (30°×30°) — long-range directional illumination
- Browse all Marine Lighting
Parts Desk Insights
SKU 265-958130511 and SKU 265-958130501 are both Seahawk 470 Wide Spread Diffused models at the same price — the distinction should be confirmed with the supplier, as it may relate to bracket configuration, regional packaging, or a minor hardware revision. The key customer education point for the Wide Spread Diffused is the difference between diffused and directional output: diffused means no defined beam angle and soft, scattered light — it will not throw light at distance the way a Spot or Spread lens will. Customers sometimes order this expecting long-range performance; confirm their use case before recommending. As with all Seahawk 470 models, this is not a COLREGS-compliant navigation light. The 5-year warranty and IP67 rating are strong selling points vs. competing brands.
