Racor S3228SUL 2-Micron Replacement Fuel Filter Element – For 320R / 490R Series

Racor S3228SUL 2-Micron Replacement Fuel Filter Element – For 320R / 490R Series

Part Number: S3228SUL (distributor SKU: 62-S3228SUL)
Brand: Racor
Type: 2-micron replacement spin-on gasoline fuel filter/water separator element
Filtration: 2 micron Aquabloc® (~98% at 4 microns)
Filter head thread: 1"-14
Bowl thread: 3.125" female
Designed for: Racor 320R-RAC-01, 320R-RAC-02, and 490R-RAC-01 assemblies
Fuel compatibility: Gasoline, ethanol-blended fuels (E10)
Certifications: UL Listed
UPC: 706672015815

Product Overview

The Racor S3228SUL is a 2-micron Aquabloc® replacement spin-on filter element for Racor 320R and 490R series gasoline fuel/water separator assemblies, including the 320R-RAC-01 clear-bowl outboard assembly, the 320R-RAC-02 metal-bowl inboard/sterndrive assembly, and the 490R-RAC-01. It provides substantially finer filtration than the standard 10-micron S3228TUL element used in the same assemblies, removing approximately 98% of 4-micron particulate while maintaining the same 1"-14 filter-head thread and S3228 format. The bowl, O-ring, drain, and mounting head are reusable and transfer to the new element at each service. Use S3228SUL when the engine manufacturer specifies a 2-micron element, or when maximum particulate and water removal is required.

• 2-micron Aquabloc® media — approx. 98% filtration efficiency at 4 microns
• Fine-filtration retrofit for 320R-RAC-01, 320R-RAC-02, and 490R-RAC-01 assemblies
• Same 1"-14 filter-head thread and S3228 format as the standard S3228TUL 10-micron element
• Compatible with ethanol-blended gasoline (E10)
• UL Listed
• Corrosion-resistant construction
• Height: approx. 4.0" / 102 mm | Outside diameter: approx. 3.8" / 97 mm
• Element only — bowl, O-ring, drain, and filter head are separate reusable components
• Weight: approx. 454 g

Element Only: The S3228SUL is the replaceable spin-on filter element. The bowl, bowl O-ring, self-venting drain, and mounting head from the existing assembly are reusable and transfer to the new element during service. For the complete 320R assembly, see the 320R-RAC-01 or 320R-RAC-02.

2-Micron vs. 10-Micron — S3228SUL vs. S3228TUL

• S3228SUL (this part) — 2 micron: Fine-filtration element for high-pressure fuel injection systems or when maximum particulate and water removal is specified. More restrictive under contaminated fuel conditions — may require shorter service intervals.
• S3228TUL — 10 micron: Standard routine-maintenance element for the same 320R/490R assemblies. Lower flow restriction. Correct for most gasoline marine applications.

Use the micron rating specified in your engine manufacturer’s service documentation. Confirm with your service manual before switching from 10-micron to 2-micron.

Compatible Applications

• Racor 320R-RAC-01 — clear-bowl outboard/above-deck assembly, 2-micron fine-filtration element
• Racor 320R-RAC-02 — metal-bowl inboard/sterndrive assembly, 2-micron fine-filtration element
• Racor 490R-RAC-01 — 2-micron fine-filtration element
• Any compatible Racor 320R/490R series assembly with a 1"-14 filter head thread accepting the S3228 element format

Fitment Note: Confirm the existing assembly uses a 1"-14 center thread before ordering. The S3228SUL is not interchangeable with elements using other thread sizes (e.g., 11/16"-16 format used in the B32013/B32020MAM families). Also confirm the correct micron rating — if 10-micron is specified, use S3228TUL instead.

Dimensions

• Height: approx. 4.0" / 102 mm
• Outside diameter: approx. 3.8" / 97 mm
• Center thread: 1"-14
• Bowl thread: 3.125" female

Service Information

Replace the S3228SUL per the engine or fuel-system manufacturer’s maintenance schedule, or sooner if fuel restriction symptoms develop (hesitation, hard starting, power loss), water accumulation is excessive, or the filter has been exposed to heavily contaminated fuel. A 2-micron element may reach its service limit sooner than a 10-micron element under high-contamination conditions — monitor bowl condition more frequently if fuel quality is a concern.

Part Number Reference

• Racor: S3228SUL
• Distributor SKU: 62-S3228SUL
• UPC: 706672015815
• Standard 10-micron version (same assemblies): S3228TUL
• Complete clear-bowl outboard assembly: Racor 320R-RAC-01
• Complete metal-bowl inboard assembly: Racor 320R-RAC-02
• Related 2-micron element (11/16"-16 thread, different family): Racor S3220SUL

Installation Notes

• Shut off the fuel supply before beginning element replacement
• Remove the bowl from the old element — inspect the bowl, O-ring, and drain for condition; replace any worn seals
• Transfer the serviceable bowl and drain to the new S3228SUL element
• Lightly lubricate the element thread and sealing surface with clean fuel or a compatible O-ring lubricant
• Thread the S3228SUL onto the 1"-14 filter head until the sealing surface seats, then hand-tighten — do not over-tighten
• Restore fuel supply, prime the fuel system per the engine manufacturer’s procedure, and inspect all connections and the bowl for leaks before starting the engine

Technical FAQ

What is the difference between S3228SUL and S3228TUL? Both fit the same 1"-14 thread Racor 320R/490R assemblies. S3228SUL is 2-micron (finer filtration, higher restriction). S3228TUL is 10-micron (standard maintenance, lower restriction). Use the rating specified in your engine’s service documentation.

What is the difference between S3228SUL and S3220SUL? Both are 2-micron Aquabloc® elements, but for different filter-head families. S3228SUL uses a 1"-14 thread for the 320R/490R series. S3220SUL uses an 11/16"-16 thread for the MerCruiser-style B32020MAM family. They are not interchangeable.

Does the S3228SUL include the bowl? No — the bowl, O-ring, and drain are separate reusable components that transfer from the old element to the new S3228SUL during service.

Is S3228SUL compatible with E10 gasoline? Yes — Aquabloc® media is compatible with ethanol-blended fuels including E10.

Related Products

• Racor 320R-RAC-01 Gasoline Fuel/Water Separator – 10 Micron | Clear Bowl | Outboard
• Racor 320R-RAC-02 Gasoline Fuel/Water Separator – 10 Micron | Metal Bowl | Inboard / Sterndrive
• Racor S3227 10-Micron Replacement Fuel Filter Element – For 320R-RAC-01 / 320R-RAC-02
• Racor S3220SUL 2-Micron Replacement Fuel Filter Element – MerCruiser-Style 11/16"-16
• Racor S3220TUL 10-Micron Replacement Fuel Filter Element – B32020MAM
• Racor 660R-RAC-01 Gasoline Fuel/Water Separator – 10 Micron | Clear Bowl | Outboard (120 GPH)
• Sierra 18-7919 Fuel/Water Separator Element – 10 Micron

Parts Desk Insights

The S3228SUL is the 2-micron version of the standard S3228 element family — not the default service part. The most important qualifying question is whether the engine or installation specifically calls for 2-micron filtration; if 10-micron is specified, the customer needs S3228TUL. A 2-micron element will restrict flow more aggressively in contaminated fuel and may clog faster, so customers should be aware that service intervals may need to be shortened if switching from 10-micron. The thread-family confusion is the most common ordering error: S3228SUL (1"-14, 320R/490R series) vs. S3220SUL (11/16"-16, MerCruiser B32020MAM family) — both are 2-micron Racor elements but are not interchangeable. The UL Listed certification is worth noting for customers certifying a new installation or replacing components on a USCG-inspected vessel.
